CEEG 220kV Single-Phase Oill Filled Traction Transformer

Brand: CEEG
Phase: Single Phase
High Voltage: 220±2*2.5% KV
Low Voltage: 27.5 kV
Type: Oil-Filled Transformer
Voltage: 16000 kVA - 90000kVA
Vector Group: I,i0
Service: Customized Service
Nature of Business: Manufacturer
Request A Quote

With the rapid development of China's high-speed railways, the voltage level of railway traction transformers continues to upgrade. The 220kV electrical grid has a large capacity, and the harmonics and negative-sequence components generated by 220kV single-phase traction transformers have a minimal impact on the 220kV electrical grid. The 220kV power supply system offers greater stability and reliability, and single-phase supply aligns better with the characteristics of railway electrification. It is characterized by simplicity in protection, lower initial investment, and the ability to reduce railway operational costs effectively. As China's economy and power system continue to evolve,220kV single-phase traction supply is an inevitable trend. The connection configuration for single-phase traction transformers is in the I-I form. Depending on capacity or user requirements, internal connections can be either series or parallel.

220kV Single-Phase Traction Transformer

Rated Capacity( kVA)

Voltage combination and tap range

Vector Group

No-load Loss (kW)

Load Loss (kW)

No-load Current %

Impedance Voltage %

High Voltage (kV)

Low Voltage (kV)

16000

220±2 x 2.5%

27.5

I,i0

16

55

0.65

10.5

20000

220±2 x 2.5%

27.5

I,i0

19

66

0.6

10.5

25000

220±2 x 2.5%

27.5

I,i0

23

77

0.6

10.5

31500

220±2 x 2.5%

27.5

I,i0

27

89

0.5

10.5

40000

220±2 x 2.5%

27.5

I,i0

32

103

0.45

10.5

50000

220±2 x 2.5%

27.5

I,i0

38

124

0.45

10.5

63000

220±2 x 2.5%

27.5

I,i0

44

148

0.4

10.5

75000

220±2 x 2.5%

27.5

I,i0

50

167

0.4

10.5

90000

220±2 x 2.5%

27.5

I,i0

57

191

0.35

10.5

production ability.png CEEG production ability 21.jpgCEEG is a professional transformer manufacturer! Our production base covers an area of more than 600 acres (40 hectares) with extensive facilities and a total construction area of 180,000 square meters. We have a professional team of more than 1,000 employees. We have advanced transformer production and testing equipment here to ensure that we provide customers with high-quality power transformer products.

We boast an array of cutting-edge equipment representing a high standard within the industry, including a complete set of shearing machines, fully automated winding machines, robot-operated stacking machines, the Hedrch Vacuum Casting Equipment, vacuum impregnation systems, air cushion transport vehicles, a fully enclosed production workshop with a cleanliness level of 100,000, 20-ton vertical winding machines, 10-ton horizontal winding machines, coal-oil gas phase drying equipment, and a 200-ton overhead crane. We adopt the latest technology and processes to ensure our products comply with international standards and customer needs.

We have a strong production capacity of 30 million kVA power transformers per year. This means we can cater to all sizes and types of power transformer needs, from small applications to large energy projects. No matter what specifications our customers require, we deliver them on time and support them with high quality and reliability.
